Same model may have multiple batches, images only for reference.

MGFS302405

Name: MGFS302405
Brand: Cosel USA, Inc.
SKU: 1078616
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGFS302405
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V / Isolated Module DC DC Converter 1 Output 5V 6A 9V - 36V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGFS (30W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	9V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Current - Output (Max)	6A
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OVP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	90%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1345
Standard Package	1
Win Source Part Number	1078616-MGFS302405
Ultra Librarian 3D Model	Ultra Librarian MGFS302405 CAD Model

Alternative Products

Description

The Cosel USA MGFS series is an isolated module type power supply with remote on/off, OCP, and OVP features.

Series: MGFS
Package: Box with a 6-DIP module
Approval: ITE (commercial)
Voltage Isolation: 1.5 kV
Number of Outputs: One
Output Voltage: 5V
Maximum Output Current: 6A
Input Voltage Range: 9V to 36V
Efficiency: 90%
Operating Temperature: -40°C to 85°C (with derating)
Dimension: 2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
