Same model may have multiple batches, images only for reference.

MGFS154805-R

Name: MGFS154805-R
Brand: Cosel USA, Inc.
SKU: 1199386
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGFS154805-R
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 15W / Isolated Module DC DC Converter 1 Output 5V 3A 18V - 76V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGFS (15W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	76V
Voltage - Output 1	5V
Current - Output (Max)	3A
Power (Watts)	15 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	88%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
Base Product Number	MGFS154805
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Standard Package	1
Win Source Part Number	1199386-MGFS154805-R
Ultra Librarian 3D Model	Ultra Librarian MGFS154805-R CAD Model

Alternative Products

Description

The MGFS154805 is an isolated module DC-DC converter manufactured by Cosel USA, Inc.

Power Output: 15 W
Efficiency: 88%
Application: ITE (Commercial)
Voltage Isolation: 1.5 kV
Current Output: 3A
Voltage Input: 18V to 76V
Output Voltage: 5V
Package: 6-DIP Module
Dimensions: 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
Temperature Range: -40°C ~ 85°C (With Derating)
HTSUS: 8504.40.9580
