Same model may have multiple batches, images only for reference.
MGFS152412 Real Image
Same model may have multiple batches, images only for reference.

MGFS152412

Part No MGFS152412
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V / Isolated Module DC DC Converter 1 Output 12V 1.3A 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr Cosel USA, Inc.
Series MGFS (15W)
Package Box
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Current - Output (Max) 1.3A
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 89%
Mounting Type Through Hole
Package / Case 6-DIP Module
Dimension 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
Other Names 1776-1338
Standard Package 1
Win Source Part Number 1180805-MGFS152412
Ultra Librarian 3D Model Ultra Librarian MGFS152412 CAD Model

Description

The Cosel USA MGFS152412 is an isolated module type DC-DC converter that operates over a temperature range of -40°C to 85°C (with derating).

  • Package: 6-DIP Module
  • Application: ITE (Commercial)
  • Voltage Isolation: 1.5 kV
  • Output Voltage: 12V
  • Maximum Output Current: 1.3A
  • Input Voltage Range: 9V to 36V
  • Series: MGFS (15W)
  • Efficiency: 89%
