Same model may have multiple batches, images only for reference.

MGFS152405

Name: MGFS152405
Brand: Cosel USA, Inc.
SKU: 1015430
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGFS152405
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V / Isolated Module DC DC Converter 1 Output 5V 3A 9V - 36V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGFS (15W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	9V
Voltage - Input (Max)	36V
Voltage - Output 1	5V
Current - Output (Max)	3A
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	88%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1337
Standard Package	1
Win Source Part Number	1015430-MGFS152405
Ultra Librarian 3D Model	Ultra Librarian MGFS152405 CAD Model

Alternative Products

Description

The MGFS152405 from Cosel USA is a 15W series power supply that is board mountable.

Type: Isolated module
Features: Remote on/off and OCP features
Package: 6-DIP module
Mounting: Through-hole
Voltage Isolation: 1.5kV
Current Output: 3A
Efficiency: 88%
Operating Temperature Range: -40°C ~ 85°C (With Derating)
ECCN: EAR99
HTSUS: 8504.40.9580
Dimension: 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
