Same model may have multiple batches, images only for reference.
MGFS10243R3 Real Image
Same model may have multiple batches, images only for reference.

MGFS10243R3

Part No MGFS10243R3
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 3.3V 8.6W / Isolated Module DC DC Converter 1 Output 3.3V 2.6A 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGFS (10W)
Package Tube
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 3.3V
Current - Output (Max) 2.6A
Power (Watts) 8.6 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 86%
Mounting Type Through Hole
Package / Case 7-SIP Module
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Base Product Number MGFS10243
Standard Package 1
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1351283-MGFS10243R3
Ultra Librarian 3D Model Ultra Librarian MGFS10243R3 CAD Model

Description

The Cosel MGFS10243R3 is a 10W isolated module DC/DC converter designed for board mount power supply applications.

  • Package: 7-SIP Module
  • Dimensions: 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
  • Input Voltage: 9V to 36V
  • Output Voltage: 3.3V
  • Efficiency: 86%
  • Operating Temperature: -40°C to 85°C
  • Application: ITE (Commercial)
