XAL4020-102MEC Coilcraft XAL4020-102MEC label picture XAL4020-102MEC real image
Same model may have multiple batches, images only for reference.
XAL4020-102MEC Coilcraft XAL4020-102MEC label picture XAL4020-102MEC real image
XAL4020-102MEC Coilcraft XAL4020-102MEC label picture XAL4020-102MEC real image
Same model may have multiple batches, images only for reference.

XAL4020-102MEC

Part No XAL4020-102MEC
Manufacturer Coilcraft
Catalog HOT - SALES and EOL Components (U - Z)
Description Shielded Power Inductors XAL4020
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Coilcraft
Win Source Part Number 404354-XAL4020-102MEC
Popularity Medium
Supply and Demand Status Limited
Package Tape & Reel (TR)
Product Status Active
Type Molded
Material - Core Metal Composite
Inductance 1µH
Tolerance ±20%
Current Rating (Amps) 9.6 A
Current - Saturation (Isat) 8.7A
Shielding Shielded
DC Resistance (DCR) 14.6mOhm Max
Frequency - Self Resonant 79MHz
Ratings AEC-Q200
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 1MHz
Mounting Type Surface Mount
Package / Case 1616 (4040 Metric)
Supplier Device Package 1616
Size / Dimension 0.157" L x 0.157" W (4.00mm x 4.00mm)
Height - Seated (Max) 0.083\
Ultra Librarian 3D Model Ultra Librarian XAL4020-102MEC CAD Model

Description

The Coilcraft XAL4020-102MEC is a medium-popularity electronic component with limited supply and demand status.
