The LS8J4M-T is a surface-mount LED manufactured by Citizen Electronics. It is designed for various indicator and backlighting applications, offering a compact size and reliable performance.

Applications

• Indicator lights on electronic devices
• Backlighting for LCDs and keypads
• Automotive lighting
• Consumer electronics
• Industrial equipment
• Signage

Features

• Compact size for space-constrained applications
• Surface-mount technology (SMT) for easy assembly
• High luminous intensity
• Wide viewing angle
• Long lifespan
• RoHS compliant

Benefits

• Enables miniaturization of electronic devices
• Reduces assembly costs
• Provides bright and clear illumination
• Offers good visibility from various angles
• Ensures long-term reliability
• Meets environmental regulations

Additional Details

The LS8J4M-T's specific characteristics, such as color, forward voltage, and luminous intensity, are detailed in Citizen Electronics' datasheet. The datasheet will also specify the typical and maximum forward current, reverse voltage, and operating temperature range. The wide viewing angle ensures that the LED is visible from different positions. The surface-mount package simplifies the assembly process and reduces manufacturing costs.

Proper soldering techniques are crucial for reliable performance. Refer to Citizen Electronics' application notes for recommended soldering profiles and handling precautions. The LED is designed for reflow soldering. It's crucial to avoid excessive heat during soldering, as this can damage the LED. The datasheet also specifies the electrostatic discharge (ESD) sensitivity of the LED, and appropriate ESD precautions should be taken during handling and assembly.
