UPD5713TK CEL UPD5713TK real image
Same model may have multiple batches, images only for reference.
UPD5713TK CEL UPD5713TK real image
UPD5713TK CEL UPD5713TK real image
Same model may have multiple batches, images only for reference.

UPD5713TK

Part No UPD5713TK
Manufacturer CEL
Catalog RF Switches
Description IC SWITCH SPDT 6-MINIMOLD
Datasheet
UPD5713TK Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Packaging Reel
Part Status Obsolete
Frequency - Lower 50MHz
Frequency - Upper 2.5GHz
Isolation @ Frequency 22.5dB @ 2.5GHz (typ)
Insertion Loss @ Frequency 0.95dB @ 2.5GHz
Topology Reflective
Circuit SPDT
P1dB 21dBm (typ) IP1dB
Impedance 50 Ohm
Temperature Range - Operating -45°C ~ 85°C
Voltage - Supply 1.8 V ~ 3.6 V
RF Type 802.15.1/Bluetooth, Cellular, PCS, WLAN, WLL
Case 6-SMD, Flat Leads
Supplier Device Package 6-Minimold
Win Source Part Number UPD5713TK-E2-A-392506
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UPD5713TK CAD Model

Description

The CEL SPDT Reflective Switch is a circuit topology switch with an impedance of 50 Ohm.

  • Impedance: 50 Ohm
  • Frequency Range: 50MHz to 2.5GHz
  • Isolation: 22.5dB @ 2.5GHz
  • Insertion Loss: 0.95dB @ 2.5GHz
  • Category: RF/IF and RFID
  • Status: Obsolete
  • Suitability: Applications that require circuit topology switches with a wide frequency range and low insertion loss.
