Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Relays
Manufacturer CEL
Packaging Tube/Rail
Status Obsolete(EOL)
Circuit SPST-NC (1 Form B)
Output Type AC, DC
Max On Resistance 30 Ohm
Load Current 150mA
Voltage - Input 1.2VDC
Voltage - Load 0 to 400 V
Mounting Through Hole
Termination Style PC Pin
Case / Package 6-DIP
Relay Type Relay
Win Source Part Number 134175-PS7141-1B
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Sensing & Instrumentation, Metering, Medical, Security, Defence, Military & Aerospace, Automation & Process Control
Ultra Librarian 3D Model Ultra Librarian PS7141-1B CAD Model

Description

The CEL 134175-PS7141-1B is a single-pole single-throw (SPST-NC) relay with an AC/DC output type.

  • Voltage Input: 1.2VDC
  • Load Current: 150mA
  • Maximum On Resistance: 30 Ohm
  • Voltage Load: 0 to 400V
  • Case: 6-DIP
  • Mounting: through a hole
  • Commonly used in: communications and networking, computers and computer peripherals, sensing and instrumentation, metering, medical, security, defence, military and aerospace, automation and process control
  • Supply and demand status: limited
