PS2811-1-F3-A Real Image PS2811-1-F3-A Real Image1 PS2811-1-F3-A Real Image2
Same model may have multiple batches, images only for reference.
PS2811-1-F3-A Real Image PS2811-1-F3-A Real Image1 PS2811-1-F3-A Real Image2
PS2811-1-F3-A Real Image PS2811-1-F3-A Real Image1 PS2811-1-F3-A Real Image2
Same model may have multiple batches, images only for reference.

PS2811-1-F3-A

Part No PS2811-1-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 2.5KV TRANS 4SOIC
Datasheet
PS2811-1-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 100% @ 1mA
Maximum DC Current Transfer Ratio 400% @ 1mA
Rise and Fall Time 4μs, 5μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 40V
Channel Output Current 40mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SSOP
Win Source Part Number 026893-PS2811-1-F3-A
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PS2811-1-F3-A CAD Model

Description

The PS2811-1-F3-A is an isolator with a transistor output designed for use in high voltage applications.

  • Product Name: PS2811-1-F3-A
  • Output Type: Transistor
  • Package: 4-SSOP
  • Category: Isolators
  • Minimum DC Current Transfer Ratio: 100% @ 1mA
  • Maximum DC Current Transfer Ratio: 400% @ 1mA
  • Switching Turn-On and Turn-Off Time: -
  • Rise Time: 4μs
  • Fall Time: 5μs
  • Maximum Output Voltage: 40V
  • Channel Output Current: 40mA
  • Continuous Forward Current-Max: 50mA
  • Supply and Demand Status: Limited
