PS2801C-4-F3-A CEL PS2801C-4-F3-A Real Image PS2801C-4-F3-A real image4955 PS2801C-4-F3-A real image4956 PS2801C-4-F3-A Real Image1 PS2801C-4-F3-A Real Image2 PS2801C-4-F3-A Real Image3 PS2801C-4-F3-A Real Image4
Same model may have multiple batches, images only for reference.
PS2801C-4-F3-A CEL PS2801C-4-F3-A Real Image PS2801C-4-F3-A real image4955 PS2801C-4-F3-A real image4956 PS2801C-4-F3-A Real Image1 PS2801C-4-F3-A Real Image2 PS2801C-4-F3-A Real Image3 PS2801C-4-F3-A Real Image4
PS2801C-4-F3-A CEL PS2801C-4-F3-A Real Image PS2801C-4-F3-A real image4955 PS2801C-4-F3-A real image4956 PS2801C-4-F3-A Real Image1 PS2801C-4-F3-A Real Image2 PS2801C-4-F3-A Real Image3 PS2801C-4-F3-A Real Image4
Same model may have multiple batches, images only for reference.

PS2801C-4-F3-A

Part No PS2801C-4-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 2.5KV 4CH TRANS 16-SSOP
Datasheet
PS2801C-4-F3-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 10μs, 7μs
Rise and Fall Time 5μs, 7μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 30mA
Forward Voltage 1.2V
Continuous forward current- Max 30mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 100488-PS2801C-4-F3-A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PS2801C-4-F3-A CAD Model

Description

The CEL PS2801C-4-F3-A is an optoisolator with a transistor output.

  • Channels: 4
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Application: Electrical isolation is required between input and output circuits
  • Isolation Voltage: 2500Vrms
  • Supply and Demand Status: Balanced
  • Temperature Range: -55°C to 100°C
  • Switching Turn-On Time: 10μs
  • Switching Turn-Off Time: 7μs
