PS2801-1-F3 Real Image PS2801-1-F3 real image12981
Same model may have multiple batches, images only for reference.
PS2801-1-F3 Real Image PS2801-1-F3 real image12981
PS2801-1-F3 Real Image PS2801-1-F3 real image12981
Same model may have multiple batches, images only for reference.

PS2801-1-F3

Part No PS2801-1-F3
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 2.5KV TRANS 4-SSOP
Datasheet
PS2801-1-F3 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Transistor, Photovoltaic Output Optoisolators
Mfr CEL
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Obsolete
Number of Channels 1
Voltage - Isolation 2500Vrms
Current Transfer Ratio (Min) 80% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Turn On / Turn Off Time (Typ) 6µs, 5µs
Rise / Fall Time (Typ) 3µs, 5µs
Input Type DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.1V
Current - DC Forward (If) (Max) 50 mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C ~ 100°C
Mounting Type Surface Mount
Package / Case 4-SOIC (0.173", 4.40mm Width)
Supplier Device Package 4-SSOP
Standard Package 3,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 656948-PS2801-1-F3
Ultra Librarian 3D Model Ultra Librarian PS2801-1-F3 CAD Model

Description

The 656948-PS2801-1-F3 is an optoisolator with a transistor output.

  • Type: Optoisolator
  • Output: Transistor
  • Input Type: DC
  • Maximum Forward Current: 50mA
  • Typical Forward Voltage: 1.1V
  • Rise Time: 3µs
  • Fall Time: 5µs
  • Voltage Isolation: 2500Vrms
  • Channel: Single
  • Maximum Output Voltage: 80V
  • Mounting: Surface mountable
  • Package: 4-SOIC
  • Operating Temperature: -55°C to 100°C
  • Status: Obsolete
  • Applications: Applications requiring electrical isolation
