PS2501-1-A Real Image PS2501-1-A Real Image1 PS2501-1-A Real Image2 PS2501-1-A Real Image3 PS2501-1-A Real Image4
Same model may have multiple batches, images only for reference.
PS2501-1-A Real Image PS2501-1-A Real Image1 PS2501-1-A Real Image2 PS2501-1-A Real Image3 PS2501-1-A Real Image4
PS2501-1-A Real Image PS2501-1-A Real Image1 PS2501-1-A Real Image2 PS2501-1-A Real Image3 PS2501-1-A Real Image4
Same model may have multiple batches, images only for reference.

PS2501-1-A

Part No PS2501-1-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 5KV TRANS 4DIP
Datasheet
PS2501-1-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Tube/Rail
Status Active
Number of Channels 1
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 80% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Rise and Fall Time 3μs, 5μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.17V
Continuous forward current- Max 80mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 100°C
Mounting Through Hole
Case / Package 4-DIP
Win Source Part Number 026861-PS2501-1-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS2501-1-A CAD Model

Description

The CEL 026861-PS2501-1-A is a through-hole transistor output type isolator with an isolation voltage of 5000Vrms.

  • Minimum DC Current Transfer Ratio: 80% @ 5mA
  • Maximum DC Current Transfer Ratio: 600% @ 5mA
  • Switching Turn-On and Turn-Off Time: Not specified
  • Rise Time: 3μs
  • Fall Time: 5μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Continuous Forward Current: max 80mA
  • Status: Common-used
  • Popularity: High
  • Supply and Demand Status: Sufficient
