Same model may have multiple batches, images only for reference.
MB03L1NZQF C&K Components – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

MB03L1NZQF

Part No MB03L1NZQF
Manufacturer C&K Components
Catalog Rotary Switches
Description SWITCH ROTARY 3POS 250MA 125V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Positions 3
Index Stops Fixed
Number of Decks 1
Number of Poles per Deck 2
Circuit per Deck DP3T
Contact Timing Non-Shorting (BBM)
Current Rating (Amps) 250mA (AC/DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 28 V
Actuator Type Flatted (3.17mm Dia)
Actuator Length 10.16mm
Angle of Throw 36°
Contact Material Copper Alloy
Contact Finish Silver
Mounting Type Panel Mount
Termination Style Solder Lug
Features IP67 - Dust Tight, Waterproof
Depth Behind Panel 14.86mm
Package Tray
Supply and Demand Status Limited
Win Source Part Number 1559526-MB03L1NZQF
Ultra Librarian 3D Model Ultra Librarian MB03L1NZQF CAD Model

Description

N
