Part No HEDS-5645#I13
Manufacturer Broadcom Limited
Catalog Encoders
Description ROTARY ENCODER OPTICAL 512PPR / Rotary Encoder Optical 512 Quadrature with Index (Incremental) Vertical
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Encoders
Mfr Broadcom Limited
Series HEDS
Package Bulk
Product Status Active
Programmable Not Verified
Encoder Type Optical
Output Type Quadrature with Index (Incremental)
Pulses per Revolution 512
Voltage - Supply 5V
Actuator Type 8mm Open Center
Detent No
Built in Switch No
Mounting Type Chassis Mount, Motors
Orientation Vertical
Termination Style Terminal Pins
Base Product Number HEDS-5645
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.4500
Win Source Part Number 920154-HEDS-5645#I13
Ultra Librarian 3D Model Ultra Librarian HEDS-5645#I13 CAD Model

Description

The HEDS-5645#I13 is an encoder from Broadcom Limited. It belongs to the HEDS series and features a vertical orientation.

  • Orientation: Vertical
  • Output Type: Quadrature with an incremental index
  • Actuator Type: 8mm open center
  • Programmable Feature: Not verified
  • Encoder Type: Optical
  • Resolution: 512 pulses per revolution
  • Detent: No detent
  • Voltage Supply: 5V
  • Applications: Chassis mount and motor
  • Package: Bulk package of 50 pieces
  • ECCN Classification: EAR99
