HCPL-6230 Broadcom Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HCPL-6230

Part No HCPL-6230
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 1.5KV 2CH PSH PUL 20LCCC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 1500VDC
Common Mode Transient Immunity (Min) 1kV/µs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 15 mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 350ns, 350ns
Rise / Fall Time (Typ) 45ns, 10ns
Voltage - Forward (Vf) (Typ) 1.3V
Current - DC Forward (If) (Max) 8mA
Voltage - Supply 4.5V ~ 20V
Temperature Range - Operating -55°C ~ 125°C
Mounting Type Surface Mount
Case / Package 20-CLCC
Supplier Device Package 20-LCCC (8.89x8.89)
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1502534-HCPL-6230
Ultra Librarian 3D Model Ultra Librarian HCPL-6230 CAD Model
