HCPL-2730-300E Real Image HCPL-2730-300E Real Image
Same model may have multiple batches, images only for reference.
HCPL-2730-300E Real Image HCPL-2730-300E Real Image
HCPL-2730-300E Real Image HCPL-2730-300E Real Image
Same model may have multiple batches, images only for reference.

HCPL-2730-300E

Part No HCPL-2730-300E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV 2CH DARL 8-DIP GW / Optocoupler DC-IN 2-CH Darlington With Base DC-OUT 8-Pin PDIP SMD Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 2
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Minimum) 300% @ 1.6mA
Current Transfer Ratio (Maximum) 2600% @ 1.6mA
Turn On / Turn Off Time (Typ) 5μs, 10μs
Input Type DC
Output Type Darlington
Output Voltage MAX 7V
Output Current per Channel 60mA
Voltage - Forward (Vf) (Typ) 1.4V
Current - DC Forward (If) (Maximum) 12mA
Vce Saturation (Maximum) 100mV
Operating Temperature Range 0°C ~ 70°C
Mounting SMD
Package 8-SMD, Gull Wing
Manufacturer Package 8-DIP Gull Wing
Win Source Part Number 775717-HCPL-2730-300E
Popularity Medium
Supply and Demand Status Limited
Quantity per package 50
Family Name HCPL-2730
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian HCPL-2730-300E CAD Model

Description

The HCPL-2730-300E from Broadcom Limited is a dual-channel Darlington isolator with an input type of DC.

  • Operating Temperature Range: 0°C to 70°C
  • Voltage Isolation: 3750Vrms
  • Output Voltage Maximum: 7V
  • Output Current Per Channel: 60mA
  • Package: 8-SMD Gull Wing
  • Family: HCPL-2730
  • Current Transfer Ratio: 300% @ 1.6mA
  • Vce Saturation: 100mV

The HCPL-2730-300E is a good choice for applications that require high voltage isolation and reliable performance.
