HCPL-0201 Real Image HCPL-0201 Real Image
Same model may have multiple batches, images only for reference.
HCPL-0201 Real Image HCPL-0201 Real Image
HCPL-0201 Real Image HCPL-0201 Real Image
Same model may have multiple batches, images only for reference.

HCPL-0201

Part No HCPL-0201
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 300ns, 300ns
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO Tall
Win Source Part Number 067852-HCPL-0201
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Signal Processing, Power Management, Industrial
Quantity per package 100
Ultra Librarian 3D Model Ultra Librarian HCPL-0201 CAD Model

Description

The Broadcom Limited 067852-HCPL-0201 is an isolator electronic component that is active in the market.

  • Packaging: Reel - TR
  • Mounting: SMD (SMT)
  • Output Type: Push-Pull, Totem Pole
  • Data Rate: 5MBd
  • Forward Voltage: 1.5V
  • Input Type: DC
  • Common Mode Transient Immunity (Min): 1kV/μs
  • Propagation Delay tpLH / tpHL (Max): 300ns, 300ns
  • Isolation Voltage: 3750Vrms
  • Applications: Computers and computer peripherals, signal processing, power management, and industrial applications
  • Supply and Demand Status: Balanced
  • Quantity per Package: 100
