HCNW2611-300E Real Image HCNW2611-300E real image4534 HCNW2611-300E Real Image
Same model may have multiple batches, images only for reference.
HCNW2611-300E Real Image HCNW2611-300E real image4534 HCNW2611-300E Real Image
HCNW2611-300E Real Image HCNW2611-300E real image4534 HCNW2611-300E Real Image
Same model may have multiple batches, images only for reference.

HCNW2611-300E

Part No HCNW2611-300E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV OPEN COLL 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.64V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 204617-HCNW2611-300E
Family Name HCNW2611
Introduction Date November 01, 2003
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 42
Ultra Librarian 3D Model Ultra Librarian HCNW2611-300E CAD Model

Description

The Broadcom Limited 204617-HCNW2611-300E is an optocoupler.

  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 10MBd
  • Forward Voltage: 1.64V
  • Common Mode Transient Immunity: 15kV/μs
  • Propagation Delay tpLH (Max): 100ns
  • Propagation Delay tpHL (Max): 100ns
  • Isolation Voltage: 5000Vrms
  • Family: HCNW2611
  • Category: Isolators
  • Operating Temperature: -40°C to 85°C
  • Package: 8-DIP Gull Wing
  • Supply Voltage: 4.5V to 5.5V
  • Rise Time: 24ns
  • Fall Time: 10ns
  • Channel Output Current: 50mA
  • Continuous Forward Current: 20mA
