HCNW137-300E Real Image HCNW137-300E Real Image
Same model may have multiple batches, images only for reference.
HCNW137-300E Real Image HCNW137-300E Real Image
HCNW137-300E Real Image HCNW137-300E Real Image
Same model may have multiple batches, images only for reference.

HCNW137-300E

Part No HCNW137-300E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV OPEN COLLECTOR 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.64V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO W
Win Source Part Number 1042479-HCNW137-300E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 42
Ultra Librarian 3D Model Ultra Librarian HCNW137-300E CAD Model

Description

The HCNW137-300E is an SMD (SMT) mounted optocoupler with open collector, Schottky clamped output type, manufactured by Broadcom Limited.

  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 10MBd
  • Forward Voltage: 1.64V
  • Input Type: DC
  • Inputs Side 1: One
  • Inputs Side 2: None
  • Common Mode Transient Immunity: 5kV/μs
  • Propagation Delay (Max): 100ns
  • Isolation Voltage: 5000Vrms
  • Temperature Range: -40°C to 85°C
  • Operating Supply Voltage: 4.5V to 5.5V
  • Channel Output Current: 50mA
  • Continuous Forward Current: 20mA
  • Package: 8-SO W
  • Popularity: Medium
  • Supply and Demand Status: Balanced
  • Package Quantity: 42
