ACPL-W483-500E Real Image ACPL-W483-500E Real Image
Same model may have multiple batches, images only for reference.
ACPL-W483-500E Real Image ACPL-W483-500E Real Image
ACPL-W483-500E Real Image ACPL-W483-500E Real Image
Same model may have multiple batches, images only for reference.

ACPL-W483-500E

Part No ACPL-W483-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV PUSH PULL 6SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Minimum) 30kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 50mA
Propagation Delay tpLH / tpHL (Maximum) 120ns, 120ns
Rise / Fall Time 6ns, 6ns
Voltage - Forward (Vf) 1.5V
Current - DC Forward (If) (Maximum) 10mA
Supply Voltage (V) 4.5V ~ 30V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 6-SOIC (0.268", 6.80mm Width)
Supplier Device Package 6-SO
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 709240-ACPL-W483-500E
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ACPL-W483-500E CAD Model

Description

The Broadcom Limited ACPL-W483-500E is a push-pull, totem pole output type isolation amplifier manufactured by Broadcom Limited. It has a data rate of unspecified and a voltage isolation of 5000Vrms.

  • Output Type: push-pull, totem pole
  • Data Rate: unspecified
  • Voltage Isolation: 5000Vrms
  • Package: 6-SO
  • Current Output per Channel: 50mA
  • Supply Voltage: 4.5V to 30V
  • Manufacturer Pack Quantity: 1
