ACPL-H342-560E Real Image ACPL-H342-560E Real Image
Same model may have multiple batches, images only for reference.
ACPL-H342-560E Real Image ACPL-H342-560E Real Image
ACPL-H342-560E Real Image ACPL-H342-560E Real Image
Same model may have multiple batches, images only for reference.

ACPL-H342-560E

Part No ACPL-H342-560E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description 2.5 Amp Output Current IGBT Gate Drive Optocoupler | OPTOISO 3.75KV 1CH GATE DRVR 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel
Technology Optical Coupling
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Minimum) 25kV/μs
Propagation Delay tpLH / tpHL (Maximum) 350ns, 250ns
Rise / Fall Time 22ns, 18ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Voltage - Forward (Vf) 1.55V
Current - DC Forward (If) (Maximum) 25mA
Voltage - Output Supply 15V ~ 30V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 8-SOIC (0.268", 6.81mm Width)
Supplier Device Package 8-SO
Approvals CSA, IEC/EN/DIN, UR
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1135386-ACPL-H342-560E
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ACPL-H342-560E CAD Model

Description

The ACPL-H342-560E is an optical coupling device with a maximum output voltage of 15V ~ 30V.

  • Approval: CSA, IEC/EN/DIN, and UR
  • Package: 8-SO
  • Temperature Range: -40°C ~ 105°C
  • Forward Voltage: 1.55V
  • DC Forward Current: 25mA
  • Common Mode Transient Immunity: 25kV/μs
  • Current Transfer Ratio: 25% @ 16mA to 60% @ 16mA
  • Rise/Fall Time: 22ns/18ns
  • Maximum Propagation Delay tpLH/tpHL: 350ns/250ns
  • Supply and Demand Status: Limited
  • Manufacturer Pack Quantity: 1
  • MSL Level: 1 (unlimited)
