ACPL-247-560E

Name: ACPL-247-560E
Brand: Broadcom Limited
SKU: 426075
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	ACPL-247-560E
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISO 3KV 4CH TRANS 16SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Number of Channels	4
Isolation Voltage	3000Vrms
Minimum DC Current Transfer Ratio	100% @ 5mA
Maximum DC Current Transfer Ratio	600% @ 5mA
Switching Turn-On and Turn-Off Time	3μs, 3μs
Rise and Fall Time	2μs, 3μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	80V
Channel Output Current	50mA
Forward Voltage	1.2V
Continuous forward current- Max	50mA
Vce Saturation (Max)	400mV
Temperature Range - Operating	-55°C to 110°C
Mounting	SMD (SMT)
Case / Package	16-SO
Win Source Part Number	1011661-ACPL-247-560E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	ACPL-247
Introduction Date	November 15, 2007
ECCN	EAR99
Country of Origin	China, Singapore
Halogen Free	Not Compliant
Estimated EOL Date	2023
Quantity per package	2k pcs
Ultra Librarian 3D Model	Ultra Librarian ACPL-247-560E CAD Model

Alternative Products

Description

The ACPL-247-560E is a transistor output optocoupler manufactured by Broadcom Limited.

Channels: Four
Package: SMD
Forward Voltage: 1.2V
Input Type: DC
Isolation Voltage: 3000Vrms
Maximum Output Voltage: 80V
Minimum DC Current Transfer Ratio: 100% @ 5mA
Maximum DC Current Transfer Ratio: 600% @ 5mA
Switching Turn-On Time: 3μs
Switching Turn-Off Time: 3μs
Rise Time: 2μs
Fall Time: 3μs
Continuous Forward Current: 50mA.
