SRU5028A-330Y Real Image
Same model may have multiple batches, images only for reference.

SRU5028A-330Y

Part No SRU5028A-330Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description Ind Power Shielded Wirewound 33uH 30% 100KHz 15Q-Factor Ferrite 800mA T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Nonstandard
Composition Wirewound
Core Material Ferrite
Current Rating 800 mA
DC Current 800 mA
DC Resistance (DCR) 260 mΩ
Depth 5.4 mm
Height 2.8 mm
Height - Seated (Max) 2.9972 mm
Inductance 33 µH
Inductance Tolerance 30 %
Length 5.207 mm
Max DC Current 800 mA
Maximum Operating Temperature 125 °C
Military Standard Not
Min Operating Temperature -40 °C
Mount Surface Mount
Packaging Tape and Reel
Ratings AEC-Q200
REACH SVHC No SVHC
RMS Current (Irms) 800 mA
RoHS Compliant
Saturation Current 680 mA
Schedule B 8504500000, 8504500000
Self Resonant Frequency 16 MHz
Shielding Shielded
Test Frequency 100 kHz
Tolerance 30 %
Width 5.207 mm
Win Source Part Number 958939-SRU5028A-330Y
Categories Fixed Inductors
Manufacturer Bourns Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian SRU5028A-330Y CAD Model

Description

The SRU5028A-330Y is a fixed inductor from Bourns Inc.

  • Inductance: 33 µH
  • Current Rating: 800 mA
  • Tolerance: 30%
  • Shielded: Yes
  • Packaging: Tape and Reel
  • Mounting Type: Surface Mount
  • Mounting: SMD (SMT)
  • AEC-Q200 Rated: Yes
  • HTSUS: 8504500000
  • RoHS Compliant: Yes
  • MSL Level: Not Applicable
