SRR7045-470M Real Image SRR7045-470M label picture SRR7045-470M real image
Same model may have multiple batches, images only for reference.
SRR7045-470M Real Image SRR7045-470M label picture SRR7045-470M real image
SRR7045-470M Real Image SRR7045-470M label picture SRR7045-470M real image
Same model may have multiple batches, images only for reference.

SRR7045-470M

Part No SRR7045-470M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description Inductor Power Shielded Wirewound 47uH 20% 1KHz 29Q-Factor Ferrite 0.95A 0.15Ohm DCR T/R / FIXED IND 47UH 950MA 150 MOHM
Datasheet
SRR7045-470M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 47μH
Tolerance ±20%
Current Rating 950mA
Current - Saturation 780mA
DC Resistance (DCR) 150 mOhm Max
Q @ Freq 29 @ 2.52MHz
Frequency - Self Resonant 11MHz
Temperature Range - Operating -40°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.189" (4.80mm)
Win Source Part Number 108076-SRR7045-470M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SRR7045
Introduction Date August 26, 2003
ECCN EAR99
Country of Origin China, Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SRR7045-470M CAD Model

Description

The SRR7045-470M is a wirewound inductor from Bourns Inc. It has an inductance of 47μH and a current rating of 950mA.

  • Height: 0.189" (4.80mm)
  • Mounting: surface-mount technology (SMT)
  • Tolerance: ±20%
  • Core Material: ferrite
  • Current Saturation: 780mA
  • Q @ Freq: 29 @ 2.52MHz
  • Self-Resonant Frequency: 11MHz
  • Frequency Test: 100kHz
  • Package: reel-TR
  • Family: SRR7045 family
  • DC Resistance (DCR): 150 mOhm Max
  • Temperature Range: -40°C to 125°C
  • ECCN: EAR99 compliant
