Same model may have multiple batches, images only for reference.
SRP7030-R15FM Real Image
Same model may have multiple batches, images only for reference.

SRP7030-R15FM

Part No SRP7030-R15FM
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 150NH 28A 0.00199OHM
Datasheet
SRP7030-R15FM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Bourns Inc.
Series SRP7030F
Package Tape & Reel
Product Status Obsolete
Material - Core Iron
Inductance 150 nH
Tolerance ±20%
Current Rating (Amps) 28 A
Current - Saturation (Isat) 37A
Shielding Shielded
DC Resistance (DCR) 1.99mOhm Max
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Features Flat Wire
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.299" L x 0.256" W (7.60mm x 6.50mm)
Height - Seated (Max) 0.118" (3.00mm)
Base Product Number SRP7030F
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 742013-SRP7030-R15FM
Ultra Librarian 3D Model Ultra Librarian SRP7030-R15FM CAD Model

Description

The SRP7030F series from Bourns Inc. is a fixed inductor designed for various electronic applications.

  • Technology: Flat wire
  • Inductance: 150 nH
  • Tolerance: ±20%
  • Size: 0.299" L x 0.256" W (7.60mm x 6.50mm)
  • Height: 0.118" (3.00mm)
  • DC Resistance (DCR): 1.99mOhm max
  • Current Rating: 28 A
  • Shielded: Yes
  • Mounting Type: Surface Mount
  • Operating Temperature: -55°C to 125°C
  • Packaging: Tape & reel
  • Standard Package Quantity: 1,000 pcs
  • Status: Obsolete
