SRP1250-R36M Real Image
Same model may have multiple batches, images only for reference.

SRP1250-R36M

Part No SRP1250-R36M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description Shielded Power Inductors
Datasheet
SRP1250-R36M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Bourns Inc.
Series SRP1250
Packaging Reel - TR
Type Wirewound
Material - Core Iron
Inductance 360nH
Tolerance ±20%
Current Rating 41A
Current - Saturation 75A
Shielding Shielded
DC Resistance (DCR) 1.1 mOhm Max
Operating Temperature Range -55°C ~ 150°C
Test Frequency 100kHz
Mounting SMD
Package Nonstandard
Size 0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Maximum) 0.232" (5.90mm)
RoHS State Request Verification
Win Source Part Number 1258810-SRP1250-R36M
Manufacturer Homepage www.bourns.com
Popularity Medium
Supply and Demand Status Limited
Family Name SRP1250
Introduction Date July 24, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian SRP1250-R36M CAD Model

Description

This electronic component is manufactured by Bourns Inc. and belongs to the SRP1250 series.

  • Win Source Part Number: 1258810-SRP1250-R36M
  • Packaging: Reel - TR
  • Type: Wirewound
  • Shielding: Shielded
  • Operating Temperature Range: -55°C ~ 150°C
  • Packaging: Nonstandard
  • Current Rating: 41A
  • Inductance: 360nH
  • Mounting Type: SMD
  • Tolerance: ±20%
  • Core Material: Iron
  • Current Saturation: 75A
  • DC Resistance (DCR): 1.1 mOhm Max
  • RoHS Compliant: Yes
  • Height When Seated (Maximum): 0.232" (5.90mm)
  • Introduction Date: July 24, 2007
