Same model may have multiple batches, images only for reference.

SRP1250-3R3M

Name: SRP1250-3R3M
Brand: Bourns Inc.
SKU: 1131947
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP1250-3R3M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	FIXED IND 3.3UH 15A 9.2 MOHM SMD / 3.3 µH Shielded Drum Core, Wirewound Inductor 15 A 9.2mOhm Max Nonstandard
Datasheet	SRP1250-3R3M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP1250
Package	Tape & Reel (TR),Cut Tape (CT)
Type	Drum Core, Wirewound
Material - Core	Iron
Inductance	3.3 µH
Tolerance	±20%
Current Rating (Amps)	15 A
Current - Saturation (Isat)	32A
Shielding	Shielded
DC Resistance (DCR)	9.2mOhm Max
Temperature Range - Operating	-55°C ~ 150°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max)	0.232" (5.90mm)
Base Product Number	SRP1250
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Other Names	-SRP1250-3R3MCT,SRP1250-3R3MTR,-SRP1250-3R3MTR,-SRP1250-3R3M,SRP12503R3M,SRP1250-3R3MCT
Standard Package	500
Win Source Part Number	1131947-SRP1250-3R3M
Ultra Librarian 3D Model	Ultra Librarian SRP1250-3R3M CAD Model

Alternative Products

Description

The Bourns Inc. 1131947-SRP1250-3R3M is a fixed inductor with a shielded drum core and wirewound type.

Inductance: 3.3 μH
Tolerance: ±20%
Packaging: tape and reel or cut tape
Height: 0.232" (5.90mm)
Standard Package: 500 units
Mounting: SMD (SMT)
Core Material: iron
DC Resistance (DCR): 9.2mOhm Max
Temperature Range: -55°C to 150°C
