Same model may have multiple batches, images only for reference.
SRP1040-3R3M Real Image
Same model may have multiple batches, images only for reference.

SRP1040-3R3M

Part No SRP1040-3R3M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description SRP1040 Series - Shielded Power Inductors
Datasheet
SRP1040-3R3M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Bourns Inc.
Series SRP1040
Packaging Reel - TR
Material - Core Iron
Inductance 3.3μH
Tolerance ±20%
Current Rating 10A
Current - Saturation 14A
Shielding Shielded
DC Resistance (DCR) 10 mOhm Max
Operating Temperature Range -55°C ~ 150°C
Test Frequency 100kHz
Mounting SMD
Package Nonstandard
Size 0.465" L x 0.413" W (11.80mm x 10.50mm)
Height - Seated (Maximum) 0.165" (4.20mm)
Win Source Part Number 1258788-SRP1040-3R3M
Manufacturer Homepage www.bourns.com
Popularity Medium
Supply and Demand Status Limited
Family Name SRP1040
Introduction Date May 09, 2006
ECCN EAR99
Country of Origin Taiwan
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian SRP1040-3R3M CAD Model

Description

The Bourns Inc. SRP1040-3R3M is a shielded inductor with an inductance of 3.3μH and a current rating of 10A. It has a tolerance of ±20% and a maximum DC resistance of 10 mOhm.

  • GPTDescription: The inductor is designed to operate in a temperature range of -55°C to 150°C and is packaged in a nonstandard package that is surface mountable.
  • GPTDescription: The SRP1040-3R3M is made of iron core material and has a current saturation of 14A.
  • GPTDescription: The inductor is part of the SRP1040 series and has a medium popularity in the market.
