SRU6013-1R5Y Real Image
Same model may have multiple batches, images only for reference.

SRU6013-1R5Y

Part No SRU6013-1R5Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRU6013-1R5Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRU6013
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 1.5 µH
Tolerance ±30%
Current Rating (Amps) 3 A
Current - Saturation (Isat) 2.4A
Shielding Shielded
DC Resistance (DCR) 40mOhm Max
Q @ Freq 10 @ 7.96MHz
Frequency - Self Resonant 90MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.256" L x 0.244" W (6.50mm x 6.20mm)
Height - Seated (Max) 0.063" (1.60mm)
Base Product Number SRU6013
Other Names SRU6013-1R5Y,SRU6013-1R5YCT,SRU6013-1R5YTR,SRU6013-1R5YDKR
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1273028-SRU6013-1R5Y
Ultra Librarian 3D Model Ultra Librarian SRU6013-1R5Y CAD Model

Description

The SRU6013-1R5Y is a drum core, wirewound fixed inductor manufactured by Bourns Inc.

  • Series: SRU6013
  • Packaging: Tape & Reel
  • Inductance: 1.5 µH
  • Tolerance: ±30%
  • Current Rating: 3 A
  • DC Resistance (DCR): 40mOhm Max
  • Height: 0.063" (1.60mm)
  • Dimension: 0.256" L x 0.244" W (6.50mm x 6.20mm)
  • Supply and Demand Status: Balanced
  • Win Source Part Number: 1273028-SRU6013-1R5Y
