The SRR12-LAB1 is a semi-shielded power inductor manufactured by Bourns Inc. Power inductors are crucial components in electronic circuits, primarily used for energy storage and filtering. The SRR12 series are designed for high-current applications and are characterized by their compact size and robust construction.

Applications

• DC-DC Converters: Used in step-up (boost), step-down (buck), and inverting converters.
• Power Supplies: Employed in linear and switching power supplies for filtering and regulation.
• LED Lighting: Found in LED drivers for current regulation.
• Portable Devices: Used in smartphones, tablets, and other portable electronics for power management.
• Automotive Electronics: Used in various automotive systems requiring efficient power conversion.

Features

• Semi-Shielded Construction: Offers a balance between cost and electromagnetic interference (EMI) performance.
• High Current Capacity: Designed to handle substantial DC current without saturation.
• Compact Size: Provides a small footprint for space-constrained applications.
• Low DC Resistance (DCR): Minimizes power loss and improves efficiency.
• RoHS Compliant: Complies with Restriction of Hazardous Substances directives, ensuring environmental friendliness.

Benefits

• Efficient Power Conversion: Improves overall system efficiency in power supply designs.
• Reduced EMI: Minimizes electromagnetic interference, contributing to a cleaner signal environment.
• Space Saving: Enables compact designs in portable and other miniaturized electronic devices.
• Reliable Performance: Provides stable inductance and current handling capabilities.
• Environmentally Friendly: Meets environmental regulations, reducing hazardous substance content.

Additional Details

The SRR12-LAB1 features a ferrite core material to achieve high inductance values. It is typically surface mountable and reflow solder compatible. Key specifications include inductance value (in microhenries), saturation current (the current at which the inductance drops to a certain percentage of its initial value), and DC resistance. The operating temperature range is also a critical factor, ensuring reliable performance across various environmental conditions. The “LAB1” likely denotes specific electrical characteristics and packaging information within the SRR12 series. Its semi-shielded construction aids in managing electromagnetic interference without the added cost of fully shielded inductors. The specific inductance value and other parameters will be detailed in the product datasheet from Bourns.
