SRP5020C-R15Y

Part No SRP5020C-R15Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5020C
Package Tape & Reel
Material - Core Metal
Inductance 150 nH
Tolerance ±30%
Current Rating (Amps) 18 A
Current - Saturation (Isat) 34A
Shielding Shielded
DC Resistance (DCR) 4mOhm Max
Q @ Freq 5 @ 100kHz
Frequency - Self Resonant 180MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP5020C-R15YDKR,118-SRP5020C-R15YCT,118-SRP5020C-R15YTR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273897-SRP5020C-R15Y
Ultra Librarian 3D Model Ultra Librarian SRP5020C-R15Y CAD Model

Description

The Bourns Inc. SRP5020C-R15Y is a fixed inductor with a shielded type.

  • Type: Shielded
  • Core Material: Metal
  • Inductance: 150 nH
  • Tolerance: ±30%
  • DC Resistance: 4mΩ max
  • Current Rating: 18A
  • Operating Temperature: -40°C to 125°C
  • Height: 0.079" (2.00mm)
  • Dimension: 0.224" L x 0.205" W (5.70mm x 5.20mm)
  • Package: Nonstandard
  • Packaging: Tape and Reel
