Same model may have multiple batches, images only for reference.
SRP5020C-R10Y Real Image
Same model may have multiple batches, images only for reference.

SRP5020C-R10Y

Part No SRP5020C-R10Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP5020C-R10Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5020C
Package Tape & Reel
Material - Core Metal
Inductance 100 nH
Tolerance ±30%
Current Rating (Amps) 20 A
Current - Saturation (Isat) 36A
Shielding Shielded
DC Resistance (DCR) 3mOhm Max
Q @ Freq 5 @ 100kHz
Frequency - Self Resonant 200MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP5020C-R10YCT,118-SRP5020C-R10YDKR,118-SRP5020C-R10YTR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273898-SRP5020C-R10Y
Ultra Librarian 3D Model Ultra Librarian SRP5020C-R10Y CAD Model

Description

The SRP5020C-R10Y inductor from Bourns Inc. is a shielded fixed inductor that is designed to provide high performance in various applications.

  • Inductance: 100 nH
  • Q @ Freq: 5 @ 100kHz
  • Temperature Range: -40°C to 125°C
  • DC Resistance (DCR): 3mOhm Max
  • Packaging: Tape and Reel
  • Standard Package: 3,000
  • Frequency Self-Resonant: 200MHz
  • Current Rating: 20A
  • Dimension: 0.224" L x 0.205" W (5.70mm x 5.20mm)
  • Core Material: Metal
  • Tolerance: ±30%
