Same model may have multiple batches, images only for reference.

SRP5020C-1R5M

Name: SRP5020C-1R5M
Brand: Bourns Inc.
SKU: 1273900
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SRP5020C-1R5M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP5020C-1R5M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP5020C
Package	Tape & Reel
Material - Core	Metal
Inductance	1.5 µH
Tolerance	±20%
Current Rating (Amps)	7 A
Current - Saturation (Isat)	9.6A
Shielding	Shielded
DC Resistance (DCR)	28.7mOhm Max
Q @ Freq	20 @ 100kHz
Frequency - Self Resonant	42MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max)	0.079" (2.00mm)
Other Names	118-SRP5020C-1R5MCT,118-SRP5020C-1R5MTR,118-SRP5020C-1R5MDKR
Standard Package	3,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1273900-SRP5020C-1R5M
Ultra Librarian 3D Model	Ultra Librarian SRP5020C-1R5M CAD Model

Alternative Products

Description

The Bourns Inc. SRP5020C-1R5M inductor is a fixed inductor that is designed for use in a wide range of applications.

Type: Shielded
Inductance: 1.5 µH
Tolerance: ±20%
DC Resistance (DCR): 28.7mOhm Max
Current Rating (Amps): 7 A
Frequency - Self-Resonant: 42MHz
Q @ Freq: 20 @ 100kHz
Temperature Range: -40°C ~ 125°C
REACH: Unaffected
Category: Inductors, Coils, Chokes>Fixed Inductors
Package: Nonstandard
Dimensions: 0.224" L x 0.205" W (5.70mm x 5.20mm)
Mounting: SMD (SMT)
Packaging: Tape & Reel
