SRP3020C-1R5M Real Image
Same model may have multiple batches, images only for reference.

SRP3020C-1R5M

Part No SRP3020C-1R5M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP3020C-1R5M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP3020C
Package Tape & Reel
Material - Core Metal
Inductance 1.5 µH
Tolerance ±20%
Current Rating (Amps) 3.7 A
Current - Saturation (Isat) 4A
Shielding Shielded
DC Resistance (DCR) 50mOhm Max
Q @ Freq 10 @ 100kHz
Frequency - Self Resonant 50MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.126" W (3.50mm x 3.20mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP3020C-1R5MTR,118-SRP3020C-1R5MDKR,118-SRP3020C-1R5MCT
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273965-SRP3020C-1R5M
Ultra Librarian 3D Model Ultra Librarian SRP3020C-1R5M CAD Model

Description

The SRP3020C-1R5M is a fixed inductor from Bourns Inc. that features a metal core and is shielded to prevent electromagnetic interference.

  • Standard Package: 3,000
  • Mounting Type: SMD (SMT)
  • Inductance: 1.5 µH
  • Tolerance: ±20%
  • DC Resistance: 50 mOhm max
  • Current Rating: 3.7 A
  • Q @ Freq: 10 @ 100kHz
  • Frequency Self-Resonant: 50MHz
  • Temperature Range: -40°C to 125°C
  • Dimension: 0.138" L x 0.126" W (3.50mm x 3.20mm)
