Same model may have multiple batches, images only for reference.

SRP1245C-1R0M

Name: SRP1245C-1R0M
Brand: Bourns Inc.
SKU: 1274070
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRP1245C-1R0M
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRP1245C-1R0M Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRP1245C
Package	Tape & Reel
Material - Core	Metal
Inductance	1 µH
Tolerance	±20%
Current Rating (Amps)	30 A
Current - Saturation (Isat)	50A
Shielding	Shielded
DC Resistance (DCR)	2.4mOhm Max
Q @ Freq	20 @ 100kHz
Frequency - Self Resonant	42MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.531" L x 0.496" W (13.50mm x 12.60mm)
Height - Seated (Max)	0.197" (5.00mm)
Other Names	118-SRP1245C-1R0MCT,118-SRP1245C-1R0MTR,118-SRP1245C-1R0MDKR
Standard Package	500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1274070-SRP1245C-1R0M
Ultra Librarian 3D Model	Ultra Librarian SRP1245C-1R0M CAD Model

Alternative Products

Description

The Bourns Inc. SRP1245C series inductor is a shielded product that has a standard package of 500.

Package/Case: Non-Standard
Mounting Type: SMD (SMT)
Material: Metal
Inductance: 1 µH
Height: 0.197" (5.00mm)
Tolerance: ±20%
Q @ Freq: 20 @ 100kHz
Frequency of Self-Resonant: 42MHz
DC Resistance (DCR): 2.4mOhm Max
Current Rating (Amps): 30A
REACH: REACH Unaffected
ECCN: EAR99
