Same model may have multiple batches, images only for reference.
SRP0612-R47K Real Image
Same model may have multiple batches, images only for reference.

SRP0612-R47K

Part No SRP0612-R47K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0612
Package Tape & Reel
Material - Core Metal
Inductance 470 nH
Tolerance ±10%
Current Rating (Amps) 7.7 A
Current - Saturation (Isat) 15.5A
Shielding Shielded
DC Resistance (DCR) 17.1mOhm Max
Q @ Freq 21 @ 25.2MHz
Frequency - Self Resonant 68MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.280" L x 0.264" W (7.10mm x 6.70mm)
Height - Seated (Max) 0.047" (1.20mm)
Other Names 118-SRP0612-R47KTR,118-SRP0612-R47KDKR,118-SRP0612-R47KCT
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274175-SRP0612-R47K
Ultra Librarian 3D Model Ultra Librarian SRP0612-R47K CAD Model

Description

The Bourns Inc. SRP0612-R47K is a fixed inductor part that belongs to the SRP0612 series.

  • Mounting: SMD (SMT)
  • Shielding: Shielded
  • Height: 0.047 inches
  • Standard Package: 2,500
  • Inductance: 470 nH
  • Tolerance: ±10 percent
  • Core Material: Metal
  • Q @ Freq: 21 @ 25.2MHz
  • Frequency of Self-Resonant: 68MHz
  • DC Resistance (DCR): 17.1mOhm Max
  • Current Rating (Amps): 7.7 A
  • Current Saturation (Isat): 15.5A
