SRP0515-2R2K Real Image
Same model may have multiple batches, images only for reference.

SRP0515-2R2K

Part No SRP0515-2R2K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0515
Package Tape & Reel
Material - Core Metal
Inductance 2.2 µH
Tolerance ±10%
Current Rating (Amps) 5.3 A
Current - Saturation (Isat) 8.3A
Shielding Shielded
DC Resistance (DCR) 38.2mOhm Max
Q @ Freq 42 @ 7.96MHz
Frequency - Self Resonant 29MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.213" L x 0.201" W (5.40mm x 5.10mm)
Height - Seated (Max) 0.059" (1.50mm)
Other Names 118-SRP0515-2R2KCT,118-SRP0515-2R2KTR,118-SRP0515-2R2KDKR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274196-SRP0515-2R2K
Ultra Librarian 3D Model Ultra Librarian SRP0515-2R2K CAD Model

Description

The Bourns Inc. SRP0515-2R2K is a high-performance fixed inductor designed for use in a variety of applications.

  • Current Rating: 5.3A
  • Q @ Freq: 42 @ 7.96MHz
  • Shielded: Yes
  • Tolerance: ±10%
  • Package/Case: Nonstandard
  • DC Resistance (DCR): 38.2mOhm Max
  • MSL Level: 1 (unlimited)
