SRP0515-1R5K

Part No SRP0515-1R5K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0515
Package Tape & Reel
Material - Core Metal
Inductance 1.5 µH
Tolerance ±10%
Current Rating (Amps) 6.3 A
Current - Saturation (Isat) 9.4A
Shielding Shielded
DC Resistance (DCR) 24.2mOhm Max
Q @ Freq 49 @ 7.96MHz
Frequency - Self Resonant 35MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.213" L x 0.201" W (5.40mm x 5.10mm)
Height - Seated (Max) 0.059" (1.50mm)
Other Names 118-SRP0515-1R5KTR,118-SRP0515-1R5KDKR,118-SRP0515-1R5KCT
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274197-SRP0515-1R5K
Ultra Librarian 3D Model Ultra Librarian SRP0515-1R5K CAD Model

Description

The Bourns Inc. SRP0515-1R5K is a shielded, surface mount inductor.

  • Inductance: 1.5 µH
  • Tolerance: ±10%
  • DC Resistance (DCR): 24.2 mOhm max
  • Current Rating: 6.3 A
  • Operating Temperature: -40°C to 125°C
  • Package / Case: Nonstandard, 0.213" L x 0.201" W (5.40mm x 5.10mm)
  • Series: SRP0515
  • Q @ Freq: 49 @ 7.96MHz
  • Frequency - Self Resonant: 35MHz
