Same model may have multiple batches, images only for reference.
SRP0320-2R2K Real Image
Same model may have multiple batches, images only for reference.

SRP0320-2R2K

Part No SRP0320-2R2K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP0320
Package Tape & Reel
Material - Core Metal
Inductance 2.2 µH
Tolerance ±10%
Current Rating (Amps) 3.4 A
Current - Saturation (Isat) 4.6A
Shielding Shielded
DC Resistance (DCR) 64.8mOhm Max
Q @ Freq 34 @ 7.96MHz
Frequency - Self Resonant 38MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.134" L x 0.122" W (3.40mm x 3.10mm)
Height - Seated (Max) 0.079" (2.00mm)
Other Names 118-SRP0320-2R2KCT,118-SRP0320-2R2KTR,118-SRP0320-2R2KDKR
Standard Package 2,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274240-SRP0320-2R2K
Ultra Librarian 3D Model Ultra Librarian SRP0320-2R2K CAD Model

Description

The SRP0320-2R2K is a fixed inductor from Bourns Inc. that has a shielded package of tape and reel.

  • Package: Tape and Reel (TR)
  • Material - Core: Metal
  • Inductance: 2.2 µH
  • Tolerance: ±10%
  • Q @ Freq: 34 @ 7.96MHz
  • Frequency Self-Resonant: 38MHz
  • DC Resistance (DCR): 64.8mOhm max
  • Current Rating: 3.4A
  • Mounting Type: SMD (SMT)
  • Temperature Range: -40°C ~ 125°C
  • Dimensions: 0.134" L x 0.122" W (3.40mm x 3.10mm)
  • ECCN: EAR99
  • REACH: Unaffected.
  • MSL level: 1 (Unlimited)
