Same model may have multiple batches, images only for reference.
SDE6603-681M Real Image
Same model may have multiple batches, images only for reference.

SDE6603-681M

Part No SDE6603-681M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE6603-681M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE6603
Package Tape & Reel (TR)
Product Status Obsolete
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 680 µH
Tolerance ±20%
Current Rating (Amps) 120 mA
Current - Saturation (Isat) 140mA
Shielding Unshielded
DC Resistance (DCR) 9.2Ohm Max
Frequency - Self Resonant 3MHz
Temperature Range - Operating -25°C ~ 105°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
Base Product Number SDE6603
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1274859-SDE6603-681M
Ultra Librarian 3D Model Ultra Librarian SDE6603-681M CAD Model

Description

The Bourns Inc. electronic component is a fixed inductor with a Win Source Part Number of 1274859-SDE6603-681M.

  • Shielding: Unshielded
  • Mounting: SMD (SMT)
  • Height: 0.115" (2.92mm)
  • Package: Tape & reel
  • Standard Package: 2,000
  • Tolerance: ±20%
  • DC Resistance (DCR): 9.2Ohm Max
  • Temperature Range: -25°C ~ 105°C
  • Current Rating: 120 mA
  • Dimension: 0.260" L x 0.175" W (6.60mm x 4.45mm)
  • Status: Obsolete
