SDE1006A-271K

Part No SDE1006A-271K
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE1006A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 270 µH
Tolerance ±10%
Current Rating (Amps) 750 mA
Current - Saturation (Isat) 850mA
Shielding Unshielded
DC Resistance (DCR) 970mOhm Max
Frequency - Self Resonant 4.3MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) 0.228" (5.80mm)
Base Product Number SDE1006A
Other Names SDE1006A-271K,SDE1006A-271KTR,SDE1006A-271KDKR,SDE1006A-271KCT
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274878-SDE1006A-271K
Ultra Librarian 3D Model Ultra Librarian SDE1006A-271K CAD Model

Description

The SDE1006A-271K is a drum core, wirewound inductor from Bourns Inc.

  • Package: Tape & Reel
  • Tolerance: ±10%
  • Inductance: 270 μH
  • DC Resistance (DCR): 970mOhm max
  • Height: 0.228" (5.80mm)
  • Dimension: 0.394" L x 0.354" W (10.00mm x 9.00mm)
  • Temperature Range: -40°C ~ 125°C
