78F220J-TR-RC

Part No 78F220J-TR-RC
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 22UH 285MA 1.2 OHM TH
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 22 µH
Tolerance ±5%
Current Rating (Amps) 285 mA
Shielding Unshielded
DC Resistance (DCR) 1.2Ohm Max
Q @ Freq 50 @ 2.5MHz
Frequency - Self Resonant 13MHz
Temperature Range - Operating -55°C ~ 105°C
Inductance Frequency - Test 2.5 MHz
Mounting Type Through Hole
Case / Package Axial
Size / Dimension 0.110" Dia x 0.280" L (2.79mm x 7.11mm)
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1531331-78F220J-TR-RC
Ultra Librarian 3D Model Ultra Librarian 78F220J-TR-RC CAD Model
