3296X-1-503LF Real Image 3296X-1-503LF real image14976
Same model may have multiple batches, images only for reference.
3296X-1-503LF Real Image 3296X-1-503LF real image14976
3296X-1-503LF Real Image 3296X-1-503LF real image14976
Same model may have multiple batches, images only for reference.

3296X-1-503LF

Part No 3296X-1-503LF
Manufacturer Bourns Inc.
Catalog Trimmer Potentiometers
Description TRIMMER 50K OHM 0.5W PC PIN
Datasheet
3296X-1-503LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Potentiometers, Variable Resistors
Manufacturer Bourns Inc.
Packaging Tube/Rail
Status Active
Resistance (Ohms) 50k
Power (Watts) 0.5W, 1/2W
Tolerance ±10%
Temperature Coefficient ±100ppm/°C
Number of Turns 25
Adjustment Type Side Adjustment
Resistive Material Cermet
Mounting Through Hole
Termination Style PC Pins
Dimension Rectangular - 0.395" x 0.190" Face x 0.395" H (10.03mm x 4.83mm x 10.03mm)
Win Source Part Number 1005037-3296X-1-503LF
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Consumer Electronics, Portable Devices, Power Management
Ultra Librarian 3D Model Ultra Librarian 3296X-1-503LF CAD Model

Description

The Bourns Inc. 3296X-1-503LF is a through-hole mount potentiometer that is used in industrial, consumer electronics, portable devices, and power management applications.

  • Resistance: 50k ohms
  • Power Rating: 0.5W (1/2W)
  • Tolerance: ±10%
  • Temperature Coefficient: ±100ppm/°C
  • Turns: 25
  • Resistive Material: Cermet
  • Package Dimensions: 0.395" x 0.190" face x 0.395" H (10.03mm x 4.83mm x 10.03mm)
  • Packaging: Tube/Rail
  • Popularity: Medium
