BTD48-12W45S Real Image
Same model may have multiple batches, images only for reference.

BTD48-12W45S

Part No BTD48-12W45S
Manufacturer Bellnix Co., Ltd.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-12V 11W / Isolated Module DC DC Converter 2 Output 12V -12V 450mA, 450mA 36V - 76V Input
Datasheet
BTD48-12W45S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Bellnix Co., Ltd.
Series BTD (10W)
Package Bulk
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 36V
Voltage - Input (Max) 76V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 450mA, 450mA
Power (Watts) 11 W
Voltage - Isolation 500 V
Applications ITE (Commercial)
Features Adjustable Output, Remote On/Off
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 86%
Mounting Type Surface Mount
Package / Case 8-SMD Module, 7 Leads
Size / Dimension 1.41" L x 0.89" W x 0.33" H (35.9mm x 22.6mm x 8.5mm)
Base Product Number BTD48
Standard Package 30
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 1340464-BTD48-12W45S
Ultra Librarian 3D Model Ultra Librarian BTD48-12W45S CAD Model

Description

Bellnix Co., Ltd. offers the BTD48 series of isolated module DC-DC converters that feature adjustable output and remote on/off control. BTD48 series is manufactured by Bellnix Co., Ltd.

  • Features: Adjustable Output, Remote On/Off Control
  • Application: ITE (Commercial)
  • Package: 8-SMD Module, 7 Leads
  • Power: 11W
  • Outputs: Two Outputs, 12V and -12V @ 450mA each
  • Input Voltage: 36V to 76V
  • Voltage Isolation: 500V
  • Efficiency: 86%
  • Temperature Range: -40°C to 85°C (with derating)
