PWB-5002 Astrodyne Corporation
Same model may have multiple batches, images only for reference.

PWB-5002

Part No PWB-5002
Manufacturer Astrodyne Corporation
Catalog Board Mount AC DC Converters
Description 5W Encapsulated PCB DIP Mount Po
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - AC DC Converters
Mfr Astrodyne Corporation
Series PWB (5W)
Package Tape & Box (TB)
Product Status Active
Type Enclosed
Number of Outputs 1
Voltage - Input 90 ~ 264 VAC
Voltage - Output 1 12V
Current - Output (Max) 420mA
Power (Watts) 5 W
Applications ITE (Commercial), Medical
Features Universal Input
Temperature Range - Operating 0°C ~ 50°C (With Derating)
Efficiency 80%
Mounting Type Through Hole
Package / Case 4-DIP Module
Size / Dimension 2.00" L x 1.01" W x 0.60" H (50.8mm x 25.6mm x 15.2mm)
Approval Agency CB, CE, cURus, UL
Standard Number 60601-1; 60950-1
Line Regulation ±0.5%
Load Regulation ±0.5%
Standard Package 1 pcs
Win Source Part Number 658261-PWB-5002
Ultra Librarian 3D Model Ultra Librarian PWB-5002 CAD Model

Description

The PWB-5002 is a 5W enclosed AC/DC converter from Astrodyne Corporation. It is part of the PWB series, specifically designed for power supplies in board mount applications.

  • Power: 5W
  • Series: PWB
  • Application: Power Supplies, Board Mount
  • Input Voltage: 90 to 264 VAC
  • Output Voltage: 12V
  • Output Current: 420mA
  • Efficiency: 80%
  • Line Regulation: ±0.5%
  • Load Regulation: ±0.5%
  • Mounting: Through-Hole
  • Package: 4-DIP module
  • Temperature: 0°C to 50°C (with derating)
  • Application: ITE (Commercial) and Medical
  • Approvals: CB, CE, cURus, UL
  • Standard Numbers: 60601-1 and 60950-1
