PTV05020WAD Emerson Network Power
Same model may have multiple batches, images only for reference.

PTV05020WAD

Part No PTV05020WAD
Manufacturer Artesyn Embedded Technologies
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 0.8-3.6V 64.8W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Artesyn Embedded Technologies
Series PTV05020 (65W)
Package Tray
Product Status Active
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 0.8 ~ 3.6V
Current - Output (Max) 18A
Power (Watts) 64.8 W
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, UVLO
Temperature Range - Operating -40°C ~ 85°C
Efficiency 96%
Mounting Type Through Hole
Package / Case 12-SIP Module
Size / Dimension 1.75" L x 0.37" W x 0.50" H (44.5mm x 9.4mm x 12.7mm)
Base Product Number PTV05020
Standard Package 84 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 658016-PTV05020WAD
Ultra Librarian 3D Model Ultra Librarian PTV05020WAD CAD Model

Description

The PTV05020WAD is a non-isolated PoL module from Artesyn Embedded Technologies. It belongs to the PTV05020 series, which is a 65W power supply designed for board mount applications in the power supplies category.

  • Series: PTV05020
  • Power Supply Type: PoL Module, Non-Isolated
  • Power: 65W
  • Application: Board Mount, Power Supplies
  • Size: 1.75" L x 0.37" W x 0.50" H
  • Power Output: 64.8W
  • Output Current: 18A
  • Input Voltage: 4.5V to 5.5V
  • Output Voltage: 0.8V to 3.6V
  • Protection: Remote On/Off, OCP, OTP, UVLO
  • Efficiency: 96%
  • Mounting: Through Hole
  • Package: 12-SIP
  • Application: ITE (Commercial)
  • Standard Package: 84 pieces
