Same model may have multiple batches, images only for reference.

1025-42K

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	1025-42K
Manufacturer	API Delevan Inc.
Catalog	Fixed Inductors
Description	FIXED IND 8.2UH 160MA 2.7 OHM TH / 8.2 µH Unshielded Inductor 160 mA 2.7Ohm Max Axial
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	API Delevan Inc.
Series	Military, MIL-PRF-M15305, MS75084
Package	Tape & Reel (TR),Cut Tape (CT)
Material - Core	Iron
Inductance	8.2 µH
Tolerance	±10%
Current Rating (Amps)	160 mA
Shielding	Unshielded
DC Resistance (DCR)	2.7Ohm Max
Q @ Freq	55 @ 7.9MHz
Frequency - Self Resonant	55MHz
Temperature Range - Operating	-55°C ~ 105°C
Inductance Frequency - Test	7.9 MHz
Mounting Type	Through Hole
Package / Case	Axial
Dimension	0.095" Dia x 0.250" L (2.41mm x 6.35mm)
RoHS Status	RoHS non-compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Other Names	DN2542INACTIVE,1134-1072-1,1134-1072-2,1134-1072-MIL,DN2542,102542K,1025-42K-1000 TR,1134-1072-1-MIL,1134-1072,1134-1072-2-MIL,DN2542-ND
Standard Package	1,000
Win Source Part Number	1218359-1025-42K
Ultra Librarian 3D Model	Ultra Librarian 1025-42K CAD Model

Alternative Products

Description

The 1025-42K from API Delevan Inc. is a fixed inductor with an iron core material.

Inductance: 8.2 µH
Tolerance: ±10%
DC Resistance (DCR): 2.7Ohm (maximum)
Current Rating (Amps): 160 mA
Series: Military, MIL-PRF-M15305, MS75084
Supply and Demand Status: limited
Mounting: through-hole
Package/Case: axial
Operating Temperature: -55°C to 105°C
