Same model may have multiple batches, images only for reference.
P36S103 Real Image
Same model may have multiple batches, images only for reference.

P36S103

Part No P36S103
Manufacturer Apem Inc.
Catalog DIP Switches
Description SWITCH ROTARY DIP HEX 100MA 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Switches
Estimated Pruduction Lead Time 18 Weeks
Features Dip Switch Hexadecimal 16 Position Surface Mount Rotary for Tool Actuator 100mA 24VDC
Manufacturer Apem Inc.
Series P36S
Package Tube
Operating Temperature Range -30°C ~ 90°C
Mounting Surface Mount
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Part Number P36SMT 103, 679-1955, P36S103-ND
Quantity per package 50
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 888346-P36S103
Ultra Librarian 3D Model Ultra Librarian P36S103 CAD Model

Description

The P36S series dip switch from Apem Inc. is a hexadecimal 16 position surface mount rotary for tool actuator switch.

  • Type: Hexadecimal 16 position rotary dip switch
  • Mounting: Surface Mount
  • Operating Temperature: -30°C to 90°C
  • Packaging: Tube
  • Popularity: Medium
  • Estimated Production Lead Time: 18 weeks
  • Alternative Part Numbers: P36SMT 103, 679-1955, and P36S103-ND
