The REF195FSZ-REEL is a high-precision voltage reference component manufactured by Analog Devices Inc. This device is part of a family of low-dropout, micropower voltage references that offer high accuracy and stability in a variety of applications. The REF195FSZ-REEL is designed to be versatile and reliable, making it an ideal choice for precision data converters, portable instrumentation, and battery-powered devices.

Key Features

• Precision Voltage: The REF195FSZ-REEL provides a stable 5V output voltage with an impressive initial accuracy of ±0.15%.
• Low Dropout Voltage: The device operates with a very low dropout voltage, enhancing performance in battery-operated systems where the supply voltage may vary.
• Low Power Consumption: With a quiescent current of only 45 µA (typical), this voltage reference is optimized for energy-sensitive applications.
• Temperature Drift: The REF195FSZ-REEL offers excellent temperature stability, boasting a low temperature coefficient of 8 ppm/°C (max) over the industrial temperature range.
• Output Current: It is capable of sourcing up to 10 mA of output current and sinking up to -5 mA, accommodating a wide range of load conditions.
• Package and Reel: Housed in a small 8-lead SOIC package, the REF195FSZ-REEL is supplied on a 13-inch reel, suitable for automated assembly processes.

Applications

The REF195FSZ-REEL is engineered for use in various applications that require a high degree of precision and reliability. Common use cases include:

• Precision data acquisition systems
• Battery-powered equipment
• Industrial and process control instrumentation
• Automotive electronics
• Medical and healthcare devices
• Portable test instruments

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the REF195FSZ-REEL is no exception. Each unit is rigorously tested to ensure it meets the high standards expected from a leading semiconductor manufacturer. With its robust design and proven performance, the REF195FSZ-REEL is a dependable component for any precision voltage reference application.
